S-15


N,N'-Bis(1-heptyloctyl)-3,4:9,10-perylenebis(dicarboximide); 2,9-bis-(1-heptyloctyl)anthra[2,1,9-def;6,5,10-d'e'f']diisoquinoline-1,3,8,10(2H,9H)-tetraone; 2,9-bis-(8-pentadecyl)anthra[2,1,9-def;6,5,10-d'e'f']diisoquinoline-1,3,8,10(2H,9H)-tetraone, RN 130296-47-8:
M.p. 129°C, orange rosetts (high temperature modification as a red powder) with crystal transformation at 50-60°. R_f (silica gel/CHCl₃) = 0.85. IR (KBr): ν = 2955 cm^-1 s, 2925 s, 2855 s, 1699 s, 1660 s, 1594 s, 1579 m, 1508 w, 1483 w, 1467 m, 1458 m, 1435 m, 1406 s, 1378 w, 1352 m, 1338 s, 1255 m, 1209 w, 1174 m, 1125 w, 1108 w, 964 w, 865 w, 856 w, 851 m, 825 w, 809 m, 796 w, 747 m, 724 w. UV (CHCl₃): λ_max (ε) = 458 nm (18670), 489 (51460), 525.5 (86040); (n-heptane): λ_max (ε) = 448.5 nm (20940), 479 (55230), 514.5 (93540). Fluorescence (CHCl₃): λ = 534 nm, 576; (n-heptane): (CHCl₃): λ = 518 nm, 558. Solid state fluorescence (orange modification): (CHCl₃): λ = 587 nm, 625; solid state fluorescence (red modification): (CHCl₃): λ = 642 nm. ¹H NMR (CDCl₃/TMS): δ = 0.83 (m, 12 H), 1.25 (m ,40 H), 2.00 (m, 8 H), 5.18 (m, 2 H), 8.50 (m, 8 H). ¹³C NMR (CDCl₃/TMS): δ 129.43, 131.25, 134.25, 163.84. MS (70 eV): m/z (%) = 812 (18), 811 (58), 810 (100) [M⁺], 794 (5), 793 (8), 602 (16), 601 (40), 600 (41), 403 (5), 393 (5), 392 (21), 391 (57), 390 (75), 373 (8). Solubility (n-heptane/20°C): 0.59 g/100 mL. C₅₄H₇₀N₂O₄(811.2) calcd. C 79.96, H 8.70, N 3.45; orange modification found: C 80.32 H 8.63 N 3.38.

References, RN 130296-47-8:

*1. Langhals, H.; Demmig, S.; Potrawa, T. ‘The relation between packing effects and solid state fluorescence of dyes’, J. Prakt. Chem. (Leipzig) 1991, 333 , 733-748.

2. Kaiser, H.; Lindner, J.; Langhals, H. ‘Synthesis of nonsymmetrically substituted perylene fluorescent dyes’, Chem. Ber. 1991, 124 , 529-35.

3. Langhals, H.; Demmig, S. ‘Perylene dyes and their use as permanent toner in electrophotography and laser printing’, Ger. Offen. 1991, DE 4007618 A1 19910912; Chem. Abstr. 1992, 116 , 117172.

4. Langhals, H.; Kaiser, H. ‘Asymmetric perylene fluorescent dyes and pigments, their preparation and use’, Ger. Offen. 1991, DE 4018830 A1 19911219; Chem. Abstr. 1992, 116, 237369.

5. Schott, H.; Von Cunow, D.; Langhals, H. ‘Labeling of liposomes with intercalating perylene fluorescent dyes’, Biochim. Biophys. Acta, Biomembranes 1992, 1110, 151-157.

6. Langhals, H. ‘Preparation of high-purity perylene-3,4,9,10-tetracarboxylic acid 3,4-anhydride 9,10-imides’, Ger. Offen. 1995, DE 4421347 A1 19951221; Chem. Abstr. 1996, 124, 263384.

7. Langhals, H. ‘Perylene amidine imide dyes, their preparation and their use’, Ger. Offen. 1995, DE 4327273 A1 19950216; Chem. Abstr. 1995, 123, 58801.

8. Langhals, H.; Jona, W. ‘The identification of carbonyl compounds by fluorescence: A novel carbonyl-derivatizing reagent’, Chem. Europ. J. 1998, 4 , 2110-2116.

9. Speckbacher, M.; Baumeister, J. ‘Use of fluorescent perylene compounds for the treatment of human hair’, PCT Int. Appl. 2005, WO 2005123012 A1 20051229; Chem. Abstr. 2005, 144, 93800.

10. Langhals, H.; Gold, J. ‘An unusual β-oxidation of N-functionalized alkyl chains by 1H-imidazole’, Helv. Chim. Acta 2005, 88, 2832-2836.

11. Scharf, Ch.; Peter, K.; Bauer, P.; Jung, Ch.; Thelakkat, M.; Koehler, J. ‘Towards the characterization of energy-transfer processes in organic donor-acceptor dyads based on triphenyldiamine and perylenebisimides’, Chem. Phys. 2006, 328, 403-409.

12. Nolde, F.; Pisula, W.; Mueller, S.; Kohl, C.; Muellen, K. ‘Synthesis and self-rganization of core-extended perylene tetracarboxdiimides with branched alkyl substituents’, Chem. Materials 2006, 18, 3715-3725.

13. Pisula, W.; Kastler, M.; Wasserfallen, D.; Robertson, J. W. F.; Nolde, F.; Kohl, C.; Muellen, K. ‘Pronounced supramolecular order in discotic donor-acceptor mixtures’, Angew. Chem., Int. Ed. 2006, 45, 819-823.

14. Langhals, H.; El-Shishtawy, R.; von Unold, P.; Rauscher, M. ‘Methoxyperylene bisimides and perylene lactam imides: novel, red fluorescent dyes’, Chem. Europ. J. 2006, 12, 4642-4645.

15. Chen, Lin X.; Xiao, Shengqiang; Yu, Luping ‘Dynamics of photoinduced electron transfer in a molecular donor-acceptor quartet’, J. Phys. Chem. B 2006, 110, 11730-11738.

16. Bauer, P.; Wietasch, H.; Lindner, S. M.; Thelakkat, M. ‘Synthesis and characterization of donor-bridge-acceptor molecule containing tetraphenylbenzidine and perylene bisimide’, Chem. Materials 2007, 19, 88-94.

17. Liang, Yongye; Chen, Lin X.; Xiao, Shengqiang; Yu, Luping ‘Photoinduced electron transfer in a molecular donor-acceptor quartet’, PMSE Preprints 2007, 96, 807-808; Chem. Abstr. 2007, 148, 108956.

18. Chen, Lin X.; Polshakov, Dmitrii; Xiao, Shengqiang; Liang, Yongye; Yu, Luping ‘Novel Nanoscale Organic Materials for Optimal Photovoltaic Functions’, Materials Research Society Symposium Proceedings 2007, Volume Date 2006, 974E(Solar Energy Conversion), Paper: 0974-CC06-11; Chem. Abstr. 2008, 149, 35188.

19. Lindner, S. M.; Kaufmann, N.; Thelakkat, M. ‘Nanostructured semiconductor block copolymers: π-π Stacking, optical and electrochemical properties’, Organic Electronics 2007, 8, 69-75.

20. Langhals, H.; El-Shishtawy, R.; Von Unold, P.; Rauscher, M. ‘Methoxyperylenebisimides and perylene lactamimides as perylene dyes with red fluorescence’, Ger. Offen. 2007, DE 102005045375 A1 20070329; Chem. Abstr. 2007, 146, 381816.

21. Koenemann, M.; Pschirer, N. G.; Muellen, K.; Nolde, F.; Pisula, W.; Mueller, S.; Kohl, C. ‘Liquid crystalline polycyclic aromatic tetracarboxylic acid derivatives as n-type semiconductors for use in organic field effect transistors and solar cells’, Eur. Pat. Appl. 2007, EP 1843407 A1 20071010; Chem. Abstr. 2007, 147, 460106.

22. Langhals, H.; Gold, J. ‘Fluorescent perylene dyes with imidazolyl groups in the side chains’, Ger. Offen. 2007, DE 102005038665 A1 20070222; Chem. Abstr. 2007, 146, 253567.

23. De Luca, G.; Liscio, A.; Nolde, F.; Scolaro, L. M.; Palermo, V.; Mullen, K.; Samori, P. ‘Self-assembly of discotic molecules into mesoscopic crystals by solvent-vapor annealing’, Soft Matter 2008, 4, 2064-2070.

24. Marcon, V.; Breiby, D. W.; Pisula, W.; Dahl, J.; Kirkpatrick, J.; Patwardhan, S.; Grozema, F.; Andrienko, D. ‘Understanding structure-mobility relations for perylene tetracarboxydiimide derivatives’, J. Am. Chem. Soc. 2009, 131, 11426-11432.

25. Wicklein, A.; Lang, A.; Muth, M.; Thelakkat, M. ‘Swallow-tail substituted liquid crystalline perylene bis-imides: Synthesis and thermotropic properties’, J. Am. Chem. Soc. 2009, 131, 14442-14453.

26. Koerzdoerfer, T.; Tretiak, S.; Kuemmel, S. ‘Fluorescence quenching in an organic donor-acceptor dyad: A first principles study’, J. Chem. Phys. 2009, 131, 034310/1-034310/8.

27. Rajaram, S.; Armstrong, P. B.; Kim, B. J.; Frechet, J. M. J. ‘Effect of addition of a diblock copolymer on blend morphology and performance of poly(3-hexylthiophene) Perylene diimide solar cells’, Chem. Materials 2009, 21, 1775-1777.

28. Hansen, M. R.; Graf, R.; Sekharan, S.; Sebastiani, D. ‘Columnar packing motifs of functionalized perylene derivatives: Local molecular order despite long-range disorder’, J. Am. Chem. Soc. 2009, 131, 5251-5256.

29. Langhals, H.; Pust, T. ‘Perylenetetracarboxylic diimide dye-containing micellar nanoparticles and applications’, Ger. Offen. 2010, DE 102009008661 A1 20100819; Chem. Abstr. 2010, 153, 336212.

30. Hofmann, C. C.; Lindner, S. M.; Ruppert, M.; Hirsch, A.; Haque, S. A.; Thelakkat, M.; Koehler, J. ‘Mutual interplay of light harvesting and triplet sensitizing in a perylene bisimide antenna-fullerene dyad’, J. Phys. Chem. B 2010, 114, 9148-9156.

31. Zorn, M.; Weber, S. A. L.; Tahir, M. N.; Tremel, W.; Butt, H.-J.; Berger, R.; Zentel, R. ‘Light induced charging of polymer functionalized nanorods’, Nano Lett. 2010, 10, 2812-2816.

32. Haberkorn, N.; Kim, S.; Kim, K.-S.; Sommer, M.; Thelakkat, M.; Sohn, B.-H.; Theato, P. ‘Template-assisted fabrication of highly ordered interpenetrating polymeric donor/acceptor nanostructures for photovoltaic applications’, Macromol. Chem. Phys. 2011, 212, 2142-2150.

33. May, F.; Marcon, V.; Hansen, M. R.; Grozema, F.; Andrienko, D. ‘Relationship between supramolecular assembly and charge-carrier mobility in perylenediimide derivatives: The impact of side chains’, J. Materials Chem. 2011, 21, 9538-9545.

34. Kamm, V.; Battagliarin, G.; Howard, I. A.; Pisula, W.; Mavrinskiy, A.; Li, Chen; Mullen, K.; Laquai, F. ‘Polythiophene:perylene diimide solar cells - the impact of alkyl-substitution on the photovoltaic performance’, Adv. Energy Materials 2011, 1, 297-302.

35. De Luca, G.; Pisula, W.; Credgington, D.; Treossi, E.; Fenwick, O.; Lazzerini, G. M.; Dabirian, R.; Orgiu, E.; Liscio, A.; Palermo, V.; et al. ‘Non-conventional processing and post-processing methods for the nanostructuring of conjugated materials for organic electronics’, Adv. Funct. Materials 2011, 21, 1279-1295.

36. Langhals, H.; Pust, T. ‘Lipophilic optical supramolecular nano devices in the aqueous phase’, Green and Sustainable Chem. 2011, 1, 1-6.

37. Battagliarin, G.; Zhao, Y.; Li, C.; Muellen, K. ‘Efficient tuning of LUMO levels of 2,5,8,11-substituted perylenediimides via copper catalyzed reactions’, Organic Lett. 2011, 13, 3399-3401.

38. Schmidt, C. D.; Lang, N.; Jux, N.; Hirsch, A. ‘A facile route to water-soluble coronenes and benzo[ghi]perylenes’, Chem. Europ. J. 2011, 17, 5289-5299, S5289/1-S5289/9.

39. Battagliarin, G.; Li, C.; Enkelmann, V.; Mullen, K. ‘2,5,8,11-Tetraboronic ester perylenediimides: A next generation building block for dye-stuff synthesis’, Organic Lett. 2011, 13, 3012-3015.

40. Huang, C.; Potscavage, W. J.; Tiwari, S. P.; Sutcu, S.; Barlow, S.; Kippelen, B.; Marder, S. R. ‘Polynorbornenes with pendant perylene diimides for organic electronic applications’, Polymer Chem. 2012, 3, 2996-3006.

41. Reichelt, H.; Gessner, T.; Muellen, K.; Li, C.; Battagliarin, G. ‘Perylene-based semiconducting materials for org. field-effect transistors’, PCT Int. Appl. 2012, WO 2012117089 A1 20120907; Chem. Abstr. 2012, 157, 453011.

42. Reichelt, H.; Gessner, T.; Muellen, K.; Li, C.; Battagliarin, G. ‘Perylene-based semiconducting materials’, U.S. Pat. Appl. Publ. 2012, US 20120226042 A1 20120906; Chem. Abstr. 2012, 157, 452843.

43. Rajaram, S.; Shivanna, R.; Kandappa, S. K.; Narayan, K. S. ‘Nonplanar perylene diimides as potential alternatives to fullerenes in organic solar cells’, J. Phys. Chem. Lett. 2012, 3, 2405-2408.

44. Reichelt, H.; Gessner, T.; Li, C.; Muellen, K.; Battagliarin, G. ‘Halogenated perylene-based semiconducting materials’, PCT Int. Appl. 2012, WO 2012152598 A1 20121115; Chem. Abstr. 2012, 157, 723172.

45. Gesser, T.; Reichelt, H.; Battagliarin, G.; Li, C.; Muellen, K. ‘Fluorinated perylene-based semiconducting materials’, PCT Int. Appl. 2013, WO 2013024026 A1 20130221; Chem. Abstr. 2013, 158, 346686.

46. Wieberger, F.; Kolb, T.; Neuber, C.; Ober, C. K.; Schmidt, H.-W. ‘Combinatorial techniques to efficiently investigate and optimize organic thin film processing and properties’, Molecules 2013, 18, 4120-4139.

47. Trofymchuk, K.; Reisch, A.; Shulov, I.; Mely, Y.; Klymchenko, A. S. ‘Tuning the color and photostability of perylene diimides inside polymer nanoparticles: towards biodegradable substitutes of quantum dots’, Nanoscale 2014, 6, 12934-12942.

48. Schmidt, R.; Paers, M.; Weller, T.; Thelakkat, M.; Koehler, J. ‘Trapping on demand: External regulation of excitation energy transfer in a photoswitchable smart matrix’, Appl. Phy. Lett. 2014, 104, 013304/1-013304/4.

49. Jiang, Wei; Ye, Long; Li, Xiangguang; Xiao, Chengyi; Tan, Fang; Zhao, Wenchao; Hou, Jianhui; Wang, Zhaohui ‘Bay-linked perylene bisimides as promising non-fullerene acceptors for organic solar cells’, Chem. Comm. (Cambridge, United Kingdom) 2014, 50, 1024-1026.

50. Kano, T. ‘Thermoelectric conversion material and thermoelectric conversion element’, PCT Int. Appl. 2015, WO 2015050113 A1 20150409; Chem. Abstr. 2015, 162, 535211.

51. Kano, T. ‘Thermoelectric conversion material and thermoelectric conversion element’, Jpn. Kokai Tokkyo Koho 2015, JP 2015070250 A 20150413; Chem. Abstr. 2015, 162, 535214.

52. Singer, J. C.; Ringk, A.; Giesa, R.; Schmidt, H.-W. ‘Melt electrospinning of small molecules’, Macromol. Materials and Engineering 2015, 300, 259-276.

53. Chellappan, K. V.; Kandappa, S. K.; Rajaram, S.; Narayan, K. S. ‘Ferroelectric polymer matrix for probing molecular organization in perylene diimides’, J. Phys. Chem. Lett. 2015, 6, 224-229.

54. Goossens, K.; Prior, M.; Pacheco, V.; Willbold, D.; Mullen, K.; Enderlein, J.; Hofkens, J.; Gregor, I. ‘Accurate diffusion coefficients of organosoluble reference dyes in organic media measured by dual-focus fluorescence correlation spectroscopy’, ACS Nano 2015, 9, 7360-7373.

55. Shoaee, S.; Deledalle, F.; Shakya-Tuladhar, P.; Shivanna, R.; Rajaram, S.; Narayan, K. S.; Durrant, J. R. ‘A comparison of charge separation dynamics in organic blend films employing fullerene and perylene diimide electron acceptors’, J. Phys. Chem. Lett. 2015, 6, 201-205.

56. Li, Yan; Li, Ming-Guang; Su, Ya-Jun; Liu, Jian-Gang; Han, Yan-Chun; Zheng, Shi-Jun ‘Room temperature homeotropic alignment of mixed-stacking columns of H6TP donors and PDI acceptors by charge transfer interactions and size match’, J. Mol. Liquids 2016, 224(Part_A), 721-729.

57. Divya, K. P.; Bertocchi, M. J.; Weiss, R. G. ‘Effects of temperature and CO₂ pressure on the emission of N,N’-dialkylated perylene diimides in poly(alkyl methacrylate) films. Are guest-host alkyl group interactions important’, J. Chem. Sciences (Berlin, Germany) 2016, 128, 119-132.

58. Robinson, M. R.; Furuta, P.; Lazarev, P. I. ‘Coiled capacitor comprising a layer of energy storage material’, PCT Int. Appl. 2016, WO 2016210349 A1 20161229; Chem. Abstr. 2016, 166, 107320.

59. Robinson, M. R.; Furuta, P.; Lazarev, P. I. ‘Coiled capacitor comprising a layer of energy storage material’, U.S. Pat. Appl. Publ. 2016, US 20160379757 A1 20161229; Chem. Abstr. 2016, 166, 107322.

60. Kong, Xiangfei; Wang, Guixia; Zhang, Haifeng; Huang, Da; Liu, Wenting; Ning, Tao ‘Benzophenanthrene-flexible bridge-perylene diimide binary compound, preparation method, and application’, Faming Zhuanli Shenqing 2016, CN 106146495 A 20161123; Chem. Abstr. 2016, 166, 58857.

61. Guo, Yikun; Li, Yunke; Awartani, Omar; Han, Han; Zhao, Jingbo; Ade, Harald; Yan, He; Zhao, Dahui ‘Improved performance of all-polymer solar cells enabled by naphthodiperylenetetraimide-based polymer acceptor’, Adv. Materials (Weinheim, Germany) 2017, 29, DOI:10.1002/adma.2017003

62. Wang, Helin; Chen, Lingcheng; Xiao, Yi ‘Heterologous perylene diimide arrays: Potential non-fullerene acceptors in organic solar cells’, Journal of Materials Chemistry C: Materials for Optical and Electronic Devices 2017, 5, 8875-8882.
