S-5
N,N‘-Bis(1-ethylpropyl)-3,4:9,10-perylenebis(dicarboximide);
2,9-bis-(1-ethylpropyl)anthra[2,1,9-def;6,5,10-d‘e‘f‘]diisoquinoline-1,3,8,10(2H,9H)-tetraone; 2,9-bis-(3-pentyl)anthra[2,1,9-def;6,5,10-d‘e‘f‘]diisoquinoline-1,3,8,10(2H,9H)-tetraone, RN 110590-81-3:
M.p. >360°C, red crystals. UV (CHCl3): λmax
(ε) = 457.5 nm (17910), 488 (50120), 524 (83560). C34H30N2O4 (530.6) calcd. C 76.96, H 5.70, N 5.28; found C 77.19, H 5.70, N 5.37.
References, RN 110590-81-3:
*1. Demmig, S.; Langhals, H. ‘Very soluble and photostable perylene fluorescent dyes’, Chem. Ber. 1988, 121, 225-230.
2. Langhals, H.; Demmig, S.; Huber, H. ‘Rotational barriers in perylene fluorescent dyes’, Spectrochim. Acta, Part A: Molecular and Biomolecular Spectroscopy 1988, 44A, 1189-1193.
3. Langhals, H. ‘Lightfast, readily soluble perylenetetracarboxylic (bis)imide fluorescent dyes’, Ger. Offen. 1988,DE 3703495 A1 19880818.
4. Langhals, H. ‘(Polymeric) perylenetetracarboxylic diimide dyes having high dielectric constants’, Ger. Offen. 1989,DE 3814647 A1 19891005.
5. Duff, J.; Hor, A. M.; Melnyk, A. R.; Teney, D. ‘Spectral response and xerographic electrical characteristics of some perylene bisimide pigments’, Proceedings of SPIE-The International Society for Optical Engineering 1990, 1253(Hard Copy Print. Mater., Media, Processes), 183-91.
6. Langhals, H.; Potrawa, T. ‘Optical memory devices containing color changeable dyes, and dyes therefor’, PCT Int. Appl. 1990, WO 9001480 A1 19900222.
7. Langhals, H.; Demmig, S. ‘Perylene dyes and their use as permanent toner in electrophotography and laser printing’, Ger. Offen. 1991, DE 4007618 A1 19910912.
8. Schott, H.; von Cunow, D.; Langhals, H. ‘Labeling of liposomes with intercalating perylene fluorescent dyes’, Biochim. Biophys. Acta, Biomembranes 1992, 1110, 151-157.
9. Duff, J. M.; Hor, A. M.; Loutfy, R. O.; Melnyk, A. R. ‘Molecular structure and photoactivity in perylene tetracarboxylic diimides’, Chem. Funct. Dyes, Proc. Int. Symp., 2nd 1993, 564-571.
10. Dittmer, J. J.; Marseglia, E. A.; Friend, R. H. ‘Electron trapping in dye/polymer blend photovoltaic cells’, Adv. Materials (Weinheim, Germany) 2000, 12, 1270-1274.
11. Petritsch, K.; Dittmer, J. J.; Marseglia, E. A.; Friend, R. H.; Lux, A.; Rozenberg, G. G.; Moratti, S. C.; Holmes, A. B. ‘Dye-based donor/acceptor solar cells’, Solar Energy Materials and Solar Cells 2000, 61, 63-72.
12. Dittmer, J. J.; Lazzaroni, R.; Leclere, Ph.; Moretti, P.; Granstrom, M.; Petritsch, K.; Marseglia, E. A.; Friend, R. H.; Bredas, J. L.; Rost, H.; et al. ‘Crystal network formation in organic solar cells’, Solar Energy Materials and Solar Cells 2000, 61, 53-61.
13. Gross, M. ‘Organic light harvesting’, Chemistry in Britain 2001, 37, 22-23.
14. Markham, J. P. J.; Anthopoulos, T. D.; Samuel, I. D. W.; Richards, G. J.; Burn, P. L.; Im, C.; Bassler, H. ‘Nondispersive hole transport in a spin-coated dendrimer film measured by the charge-generation-layer time-of-flight method’, Appl. Phys. Lett. 2002, 81, 3266-3268.
15. Schmidt-Mende, L.; Fechtenkotter, A.; Mullen, K.; Friend, R. H.; MacKenzie, J. D. ‘Efficient organic photovoltaics from soluble discotic liquid crystalline materials’, Physica E: Low-Dimensional Systems & Nanostructures (Amsterdam, Netherlands) 2002, 14, 263-267.
16. Neuteboom, E. E.; Beckers, E. H. A.; Meskers, S. C. J.; Meijer, E. W.; Janssen, R. A. J. ‘Singlet-energy transfer in quadruple hydrogen-bonded oligo(p-phenylenevinylene)perylene-diimide dyads’, Organic & Biomolecular Chem. 2003, 1, 198-203.
17. Miskiewicz, P.; Rybak, A.; Jung, J.; Glowacki, I.; Ulanski, J.; Geerts, Y.; Watson, M.; Mullen, K. ‘Photogeneration and transport in thin films of p- and n-?type discotic liquid crystals’, Synthetic Metals 2003, 137, 905-906.
18. Im, C.; Tian, W.; Bassler, H.; Fechtenkotter, A.; Watson, M. D.; Mullen, K. ‘Photoconduction in organic donor-acceptor systems’, J. Chem. Phys. 2003, 119, 3952-3957.
19. Schmidt-Mende, L.; Watson, M.; Muellen, K.; Friend, R. H. ‘Organic thin film photovoltaic devices from discotic materials’, Molecular Crystals and Liquid Crystals 2003, 396, 73-90.
20. Im, C.; Tian, W.; Bassler, H.; Fechtenkotter, A.; Watson, M. D.; Mullen, K. ‘Exciton dissociation in polyphenylenevinylene derivative:perylenediimide and hexabenzocoronene derivative:perylenediimide blend systems’, Synthetic Metals 2003, 139, 683-686.
21. Neuteboom, Edda E.; Meskers, Stefan C. J.; Van Hal, Paul A.; Van Duren, Jeroen K. J.; Meijer, E. W.; Janssen, Rene A. J.; Dupin, Helene; Pourtois, Geoffrey; Cornil, Jerome; Lazzaroni, Roberto; et al. ‘Alternating oligo(p-phenylene vinylene)-perylene bisimide copolymers: Synthesis, photophysics, and photovoltaic properties of a new class of donor-acceptor materials’, J. Am. Chem. Soc. 2003, 125, 8625-8638.
22. Sager, B.; Roscheisen, M.; Petritsch, K.; Pichler, K.; Fidanza, J.; Yu, D. ‘ Photovoltaic devices fabricated by growth from porous template’, PCT Int. Appl. 2004, WO 2004044948 A2 20040527.
23. Neuteboom, E. E.; Meskers, S. C. J.; Meijer, E. W.; Janssen, R. A. J. ‘Photoluminescence of self-organized perylene bisimide polymers’, Macromolecular Chemistry and Physics 2004, 205, 217-222.
24. Tian, Wen-Jing; Wang, Huan ‘Photogenerated carriers in organic doped systems’, Gaodeng Xuexiao Huaxue Xuebao 2004, 25, 1128-1131.
25. Neuteboom, Edda E.; van Hal, Paul A.; Janssen, Rene A. J. ‘Donor-acceptor polymers: A conjugated oligo(p-phenylene vinylene) main chain with dangling perylene bisimides’, Chemistry - A European Journal 2004, 10, 3907-3918.
26. Roscheisen, M. R.; Sager, B. M.; Pichler, K. ‘Photovoltaic devices fabricated from insulating nanostructured template’, U.S. Pat. Appl. Publ. 2005, 27. Sager, B. M.; Roscheisen, M. R.; Petritsch, K.; Pichler, K.; Fidanza, J.; Yu, D. ‘Photovoltaic devices fabricated by growth from porous template’, U.S. Pat. Appl. Publ. 2005, US 20050121068 A1 20050609. 28. Robeson, L. M.; Jiang, X.; Burgoyne, W. F. ‘Photovoltaic devices comprising layer(s) of photoactive organics dissolved in high Tg polymers’, U.S. Pat. Appl. Publ. 2005, US 20050022865 A1 20050203. 29. Jung, J.; Rybak, A.; Slazak, A.; Bialecki, S.; Miskiewicz, P.; Glowacki, I.; Ulanski, J.; Rosselli, S.; Yasuda, A.; Nelles, G.; et al. ‘Photogeneration and photovoltaic effect in blends of derivatives of hexabenzocoronene and perylene’, Synthetic Metals 2005, 155, 150-156. 30. Schmidtke, J. P.; Mullen, K.; Friend, R. H. ‘Controlling organization in photovoltaic diodes from discotic liquid crystals via anode surface energy alteration’, Materials Research Society Symposium Proceedings 2005, 836(Materials for Photovoltaics, 93-98. 31. Kira, A.; Umeyama, T.; Matano, Y.; Yoshida, K.; Isoda, S.; Isosomppi, M.; Tkachenko, N. V.; Lemmetyinen, H.; Imahori, H. ‘Structure and Photoelectrochemical Properties of Phthalocyanine and Perylene Diimide Composite Clusters Deposited Electrophoretically on Nanostructured SnO2 Electrodes’, Langmuir 2006, 22, 5497-5503. 32. Helbley, J. A. ‘Structural effects on perylene bis(dicarboximide) organization in aqueous and solid phase’, Diss. Abstr. Int., B, 2006, 67, 3137. 33. Singh, Th. B.; Erten, S.; Guenes, S.; Zafer, C.; Turkmen, G.; Kuban, B.; Teoman, Y.; Sariciftci, N. S.; Icli, S. ‘Soluble derivatives of perylene and naphthalene diimide for n-channel organic field-effect transistors’, Organic Electronics 2006, 7, 480-489. 34. Liscio, A.; Palermo, V.; Gentilini, D.; Nolde, F.; Mullen, K.; Samori, P. ‘Quantitative measurement of the local surface potential of π-conjugated nanostructures: A Kelvin probe force microscopy study’, Adv. Funct. Materials 2006, 16, 1407-1416. 35. Li, J.; Dierschke, F.; Wu, J.; Grimsdale, A. C.; Muellen, K. ‘Poly(2,7-carbazole) and perylene tetracarboxydiimide: A promising donor/acceptor pair for polymer solar cells’, Journal of Materials Chemistry 2006, 16(1, 96-100. 36. Palermo, V.; Morelli, S.; Palma, M.; Simpson, C.; Nolde, F. Herrmann, A. Mullen, K. Samori, P. ‘Nanoscale structural and electronic properties of ultrathin blends of two polyaromatic molecules: a Kelvin probe force microscopy investigation’, ChemPhysChem 2006, 7, 847-853. 37. Podhajecka, K.; Pfleger, J. ‘Influence of the morphology of organic heterojunction on the photovoltaic cell performance’, Europ.Phys. J.: Applied Physics 2006, 36, 241-244. 38. Beckers, E. H. A.; Meskers, S. C. J.; Schenning, A. P. H. J.; Chen, Z.; Wuerthner, F.; Marsal, P.; Beljonne, D.; Cornil, J.; Janssen, R. A. J. ‘Influence of intermolecular orientation on the photoinduced charge transfer kinetics in self-assembled aggregates of donor-acceptor arrays’, J. Am. Chem. Soc. 2006, 128, 649-657. 39. Schmidtke, J. P.; Friend, R. H.; Kastler, M.; Mullen, K. ‘Control of morphology in efficient photovoltaic diodes from discotic liquid crystals’, J. Chem. Phys. 2006, 124, 174704/1-174704/6. 40. Rybak, A.; Pfleger, J.; Jung, J.; Pavlik, M.; Glowacki, I.; Ulanski, J.; Tomovic, Z.; Muellen, K.; Geerts, Y. ‘Charge carrier transport in layers of discotic liquid crystals as studied by transient photocurrents’, Synthetic Metals 2006, 156, 302-309. 41. Zhou, Yin-Hua; Yang, Zhong-Feng; Wu, Wei-Cai; Xia, Hai-Jian; Wen, Shan-Peng; Tian, Wen-Jing ‘Solvent and electric field dependence of the photocurrent generation in donor:acceptor blend system’, Chinese Physics (Beijing, China) 2007, 16, 2136-2141. 42. Percec, V.; Aqad, E.; Peterca, M.; Imam, M. R.; Glodde, M.; Bera, T. K.; Miura, Y.; Balagurusamy, V. S. K.; Ewbank, P. C.; Wuerthner, F.; et al. ‘Self-assembly of semifluorinated minidendrons attached to electron-acceptor groups into pyramidal columns’, Chem. Europ. J. 2007, 13, 3330-3345. 43. Rajasingh, P.; Cohen, R.; Shirman, E.; Shimon, L. J. W.; Rybtchinski, B. ‘Selective bromination of perylene diimides under mild conditions’, J. Org. Chem. 2007, 72, 5973-5979. 44. Palermo, V.; Liscio, A.; Gentilini, D.; Nolde, F.; Mullen, K.; Samori, P. ‘Scanning probe microscopy investigation of self-organized perylenetetracarboxdiimide nanostructures at surfaces: Structural and electronic properties’, Small 2007, 3, 161-167. 45. Zhang, Xinping; Sun, Baoquan ‘Organic crystal fibers aligned into oriented bundles with polarized emission’, J. Phys. Chem. B 2007, 111, 10881-10885. 46. Li, J.; Kastler, M.; Pisula, W.; Robertson, J. W. F.; Wasserfallen, D.; Grimsdale, A. Clive; Wu, J.; Muellen, K. ‘Organic bulk-heterojunction photovoltaics based on alkyl substituted discotics’, Advanced Functional Materials 2007, 17, 2528-2533. 47. Miskiewicz, P.; Rybak, A.; Jung, J.; Glowacki, I.; Maniukiewicz, W.; Tracz, A.; Pfleger, J.; Ulanski, J.; Muellen, K. ‘One-step method of producing uniaxially oriented layers of organic discotic molecules for field-effect transistors’, Nonlinear Optics, Quantum Optics 2007, 37, 207-218. 48. De Luca, G.; Liscio, A.; Maccagnani, P.; Nolde, F.; Palermo, V.; Mullen, K.; Samori, P. ‘Nucleation-governed reversible self-assembly of an organic semiconductor at surfaces: Long-range mass transport forming giant functional fibers’, Adv. Funct. Materials 2007, 17, 3791-3798. 49. Zhang, Xinping; Wang, Li; Song, Yanrong ‘Method for growing large-scale crystal fiber of organic molecules’, Faming Zhuanli Shenqing 2007, CN 101003913 A 20070725. 50. Capps, P.; Adriani, P.; Sheats, J. R. ‘Individually encapsulated solar cells and solar cell strings having a hybrid organic/inorganic protective layer’, U.S. Pat. Appl. Publ. 2007, US 20070295389 A1 20071227. 51. Leidholm, C.; Bollman, B.; Sheats, J. R.; Kao, S.; Roscheisen, M. R. ‘Formation of solar cells with conductive barrier layers and foil substrates’, U.S. Pat. Appl. Publ. 2007, US 20070000537 A1 20070104. 52. Wu, Wei-Cai; Zhou, Yin-Hua; Wen, Shan-Peng; Liang, Han; Tian, Wen-Jing ‘Effect of solvent on the performance of poly(2-methoxy-5-(2-ethyl- hexyloxy)-p-phenylene vinylene): N,N'-bis(1-ethylpropyl)-3,4,9,10-perylene bis(tetracarboxyl diimide) solar cells’, Wuli Xuebao 2007, 56, 5003-5008. 53. Wang, Ya-Nan; Zhou, Yin-Hua; Xu, Yue; Sun, Xiao-Bo; Wu, Wei-Cai; Tian, Wen-Jing; Liu, Yun-Qi ‘X-shape oligo(thiophene)s as donor materials for vacuum-deposited organic photovoltaic cells’, Chinese Physics B 2008, 17, 1448-1453. 54. Keivanidis, P. E.; Greenham, N. C.; Sirringhaus, H.; Friend, R. H.; Blakesley, J. C.; Speller, R.; Campoy-Quiles, M.; Agostinelli, T.; Bradley, D. D. C.; Nelson, J. ‘X-ray stability and response of polymeric photodiodes for imaging applications’, Applied Phys. Lett. 2008, 92, 023304/1-023304/3. 55. Feng, X.; Liu, M.; Pisula, W.; Takase, M.; Li, J.; Muellen, K. ‘Supramolecular organization and photovoltaics of triangle-shaped discotic graphenes with swallow-tailed alkyl substituents’, Adv. Materials (Weinheim, Germany) 2008, 20, 2684-2689. 56. Adriani, P. M.; Scholz, J.; Roscheisen, M. R. ‘Structures for low cost, reliable solar modules’, PCT Int. Appl. 2008, WO 2008136872 A2 20081113. 57. Tuesuwan, B.; Kern, J. T.; Thomas, P. W.; Rodriguez, M.; Li, J.; David, W. M.; Kerwin, M. ‘Simian virus 40 large T-antigen G-quadruplex DNA helicase inhibition by G-quadruplex DNA-interactive agents’, Biochemistry 2008, 47, 1896-1909. 58. De Luca, G.; Liscio, A.; Nolde, F.; Scolaro, L. M.; Palermo, V.; Mullen, K.; Samori, P. ‘Self-assembly of discotic molecules into mesoscopic crystals by solvent-vapor annealing’, Soft Matter 2008, 4, 2064-2070. 59. Rybtchinski, B.; Rajasingh, P.; Shirman, E. ‘Selective bromination of perylene diimides using bromine in a chlorinated solvent at reflux’, PCT Int. Appl. 2008, WO 2008139452 A2 20081120. 60. Leidholm, C. R.; Bollman, B.; Sheats, J. R.; Kao, S.; Roscheisen, M. R.‘Photovoltaic devices with conductive barrier layers and foil substrates’, U.S. Pat. Appl. Publ. 2008, US 20080308148 A1 20081218. 61. Liscio, A.; De Luca, G.; Nolde, F.; Palermo, V.; Muellen, K.; Samori, P. ‘Photovoltaic charge generation visualized at the nanoscale: A proof of principle’, J. Am. Chem. Soc. 2008, 130, 780-781. 62. Podhajecka, K.; Matejicek, P.; Vohlidal, J.; Masuda, T.; Pfleger, J. ‘Photoelectrical behavior of perylene derivative/π-conjugated polymer system’, Synthetic Metals 2008, 158, 775-781. 63. Dabirian, R.; Palermo, V.; Liscio, A.; Schwartz, E.; Otten, M. B. J.; Finlayson, C. E.; Treossi, E.; Friend, R. H.; Calestani, G.; Mullen, K.; et al. ‘The relationship between nanoscale architecture and charge transport in conjugated nanocrystals bridged by multichromophoric polymers’, J. Am. Chem. Soc. 2009, 131, 7055-7063. 64. Lehmann, D.; Zahn, D. R. T. ‘The electrical and dielectrical behavior of n-conducting perylene tetracarboxylic diimide derivatives’, Appl. Phys. A: Materials Science & Processing 2009, 95, 203-207. 65. Nakazono, S.; Easwaramoorthi, S.; Kim, D.; Shinokubo, H.; Osuka, A. ‘Synthesis of arylated perylene bisimides through C-H bond cleavage under ruthenium catalysis’, Organic Lett. 2009, 11, 5426-5429. 66. Nakazono, S.; Imazaki, Y.; Yoo, H.; Yang, J.; Sasamori, T.; Tokitoh, N.; Cedric, T.; Kageyama, H.; Kim, D.; Shinokubo, H.; et al ‘Regioselective Ru-catalyzed direct 2,5,8,11-alkylation of perylene bisimides’, Chem. Europ. J. 2009, 15, 7530-7533, S7530/1-S7530/25. 67. Aoki, H.; Takahashi, T.; Tamai, Y.; Sekine, R.; Aoki, S.; Tani, K.; Ito, S. ‘Poly(methacrylate)s labeled by perylene diimide: synthesis and applications in single chain detection studies’, Polymer Journal (Tokyo, Japan) 2009, 41, 778-783. 68. Howard, I. A.; Laquai, F.; Keivanidis, P. E.; Friend, R. H.; Greenham, N. C. ‘Perylene tetracarboxydiimide as an electron acceptor in organic solar cells: A study of charge generation and recombination’, J. Phys. Chem. C 2009, 113, 21225-21232. 69. Serkovic L., L. N.; Hamoudi, H.; Gayone, J. E.; Martiarena, M. L.; Sanchez, E. A.; Grizzi, O.; Pasquali, L.; Nannarone, S.; Doyle, B. P.; Dablemont, C.; et al. ‘Growth of N,N'-bis(1-ethylpropyl)perylene-3,4,9,10-tetracarboxdiimide films on Ag (111)’, J. Phys. Chem. C 2009, 113, 17866-17875. 70. Provencher, F.; Laprade, J.-F.; Cote, M-; Silva, C. ‘Excitons in perylene tetracarboxdiimide crystals for optoelectronics’, Physica Status Solidi C: Current Topics in Solid State Physics 2009, 6, 93-96. 71. Friedel, B.; Keivanidis, P. E.; Brenner, T. J. K.; Abrusci, A.; McNeill, C. R.; Friend, . H.; Greenham, N. C. ‘Effects of Layer Thickness and Annealing of PEDOT:PSS Layers in Organic Photodetectors’, Macromolecules (Washington, DC, United States) 2009, 42, 6741-6747. 72. Rajaram, S.; Armstrong, P. B.; Kim, B. J.; Frechet, J. M. J. ‘Effect of addition of a diblock copolymer on blend morphology and performance of poly(3-hexylthiophene):perylene diimide solar cells’, Chemistry of Materials 2009, 21, 1775-1777. 73. Guo, Xiaoyang; Bu, Laju; Zhao, Yun; Xie, Zhiyuan; Geng, Yanhou; Wang, Lixiang ‘Controlled phase separation for efficient energy conversion in dye/polymer blend bulk heterojunction photovoltaic cells’, Thin Solid Films 2009, 517, 4654-4657. 74. Serkovic L., L. N.; Sanchez, E. A.; Gayone, J. E.; Grizzi, O.; Esaulov, V. A .‘Assembly and thermal stability of thin EP-PTCDI films on Ag(111)’, Physical Chemistry Chemical Physics 2009, 11, 3849-3853. 75. Keivanidis, P. E.; Ho, P. K. H.; Friend, R. H.; Greenham, N. C. ‘The dependence of device dark current on the active-layer morphology of solution-processed organic photodetectors’, Adv. Functional Materials 2010, 20, 3895-3903. 76. Singh-Rachford, T. N.; Nayak, A.; Muro-Small, M. L.; Goeb, S.; Therien, M. J.; Castellano, F. N. ‘Supermolecular-chromophore-sensitized near-infrared-to-visible photon upconversion’, J. Am. Chem. Soc. 2010, 132, 14203-14211. 77. Serkovic Loli, L. N.; Sanchez, E. A.; Grizzi, O.; Arista, N. R. ‘Stopping power of fluorides and semiconductor organic films for low-velocity protons’, Phys. Rev. A: Atomic, Molecular, and Optical Physics 2010, 81, Pt. A, 022902/1-022902/7. 78. Wiatrowski, M.; Dobruchowska, E.; Maniukiewicz, W.; Pietsch, U.; Kowalski, J.; Szamel, Z.; Ulanski, J. ‘Self-assembly of perylenediimide based semiconductor on polymer substrate’, Thin Solid Films 2010, 518, 2266-2270. 79. Langhals, H.; Pust, T. ‘Perylenetetracarboxylic diimide dye-containing micellar nanoparticles and applications’, Ger. Offen. 2010, DE 102009008661 A1 20100819. 80. Mizoshita, N.; Tani, T.; Inagaki, S.; Shinokubo, H. ‘Organic silica-type (mesoporous) materials having perylenebisimide skeleton and showing predetermined light absorption’, Jpn. Kokai Tokkyo Koho 2010, JP 2010196019 A 20100909. 81. Geng, Yanhou; Bu, Laju; Guo, Xiaoyang; Yu, Bo; Qu, Yao; Xie, Zhiyuan; Yan, Donghang; Wang, Fosong ‘Liquid crystalline D-A conjugated oligomers capable of forming well-defined nanostructured films for high performance single-molecular organic solar cells’, PMSE Preprints 2010. 82. Hesse, H. C.; Weickert, J.; Al-Hussein, M.; Doessel, L.; Feng, X.; Muellen, K.; Schmidt-Mende, L. ‘Discotic materials for organic solar cells: Effects of chemical structure on assembly and performance’, Solar Energy Materials & Solar Cells 2010, 94, 560-567. 83. Keivanidis, P. E.; Kamm, V.; Dyer-Smith, C.; Zhang, W.; Laquai, F.; McCulloch, I.; Bradley, D. D. C.; Nelson, J. ‘Delayed luminescence spectroscopy of organic photovoltaic binary blend films: probing the emissive non-geminate charge recombination’, Adv. Materials (Weinheim, Germany) 2010, 22, 5183-5187. 84. Maniukiewicz, W.; Bojarska, J.; Olczak, A.; Dobruchowska, E.; Wiatrowski, M. ‘2,9-Di-3-pentylanthra[2,1,9-def:6,5,10-d'e'f']diisoquinoline-1,3,8,10-tetrone’, Acta Crystallographica, Section E: Structure Reports Online 2010, 66, o2570-o2571. 85. Roscheisen, M.; Adriani, P.l ‘Thermal management for photovoltaic devices’, U.S. 2011, US 7985919 B1 20110726. 86. Handa, N. V.; Mendoza, K. D.; Shirtcliff, L. D. ‘Syntheses and properties of 1,6 and 1,7 perylene diimides and tetracarboxylic dianhydrides’, Organic Lett. 2011, 13, 4724-4727. 87. Singh-Rachford, T. N.; Nayak, A.; Muro-Small, M. L.; Goeb, S.; Therien, M. J.; Castellano, F. N. ‘Supermolecular-chromophore-sensitized near-infrared-to-visible photon upconversion. [Erratum to document cited in CA153:492177]’, J. Am. Chem. Soc. 2011, 133, 2791. 88. Al-Hussein, M.; Hesse, H. C.; Weickert, J.; Doessel, L.; Feng, X.; Muellen, K.; Schmidt-Mende, L. ‘Structural properties of the active layer of discotic hexabenzocoronene/perylenediimide bulk heterojunction photovoltaic devices: The role of alkyl side chain length’, Thin Solid Films 2011, 520(1, 307-313. 89. Stingelin, N.; Baklar, M.; Smith, P. ‘Solid-state processing of pi-conjugated materials’, PCT Int. Appl. 2011, WO 2011147819 A2 20111201. 90. Keivanidis, P. E.; Laquai, F.; Howard, I. A.; Friend, R. H. ‘Room-temperature phase demixing in bulk heterojunction layers of solution-processed organic photodetectors: The effect of active layer aging on the device electro-optical properties’, Adv. Functional Materials 2011, 21, 1355-1363. 91. Kamm, V.; Battagliarin, G.; Howard, I. A.; Pisula, W.; Mavrinskiy, A.; Li, C.; Mullen, K.; Laquai, F. ‘Polythiophene:perylene diimide solar cells - the impact of alkyl-substitution on the photovoltaic performance’, Adv. Energy Materials 2011, 1, 297-302. 92. Hesse, H. C.; Weickert, J.; Hundschell, C.; Feng, X.; Muellen, K.; Nickel, B.; Mozer, . J.; Schmidt-Mende, L. ‘Perylene sensitization of fullerenes for improved performance in organic photovoltaics’, Adv. Energy Materials 2011, 1, 861-869. 93. Quinn, J.; Zheng, Y.; Chen, Z.; Usta, H.; Newman, C.; Yan, H.; Facchetti, A. ‘Organic semiconductors and devices incorporating same’, U.S. Pat. Appl. Publ. 2011, US 20110155247 A1 20110630. 94. De Luca, G.; Pisula, W.; Credgington, D.; Treossi, E.; Fenwick, O.; Lazzerini, G. M.; Dabirian, R.; Orgiu, E.; Liscio, A.; Palermo, V.; et al. ‘Non-conventional processing and post-processing methods for the nanostructuring of conjugated materials for organic electronics’, Adv. Functional Materials 2011, 21, 1279-1295. 95. Langhals, H.; Pust, T. ‘Lipophilic optical supramolecular nano devices in the aqueous phase’, Green and Sustainable Chemistry 2011, 1, 1-6. 96. Teraoka, T.; Hiroto, S.; Shinokubo, H. ‘Iridium-catalyzed direct tetraborylation of perylene bisimides’, Organic Lett. 2011, 13, 2532-2535. 97. Capps, P.; Adriani, P.; Sheats, J. R. ‘Individually encapsulated solar cells and solar cell strings’, U.S. 2011, US 8039739 B1 20111018. 98. Yang, Yang; Wang, Yaochuan; Xie, Yuanpeng; Xiong, Tao; Yuan, Zhongyi; Zhang, Youdi; Qian, Shixiong; Xiao, Yi ‘Fused perylenebisimide-carbazole: New ladder chromophores with enhanced third-order nonlinear optical activities’, Chem. Comm. (Cambridge, United Kingdom) 2011, 47, 10749-10751. 99. Bu, Laju; Guo, Xiaoyang; Yu, Bo; Fu, Yingying; Qu, Yao; Xie, Zhiyuan; Yan, Donghang; Geng, Yanhou; Wang, Fosong ‘Donor-acceptor liquid crystalline conjugated cooligomers for the preparation of films with the ideal morphology for bulk heterojunction solar cells’, Polymer 2011, 52, 4253-4260. 100. Mohamad, D. K.; Fischereder, A.; Yi, H.-N.; Cadby, A. J.; Lidzey, D. G.; Iraqi, A. ‘A novel 2,7-linked carbazole based "double cable" polymer with pendant perylene diimide functional groups: Preparation, spectroscopy and photovoltaic properties’, J. Materials Chemistry 2011, 21, 851-862. 101. Battagliarin, G.; Li, C.; Enkelmann, V.; Mullen, K. ‘2,5,8,11-Tetraboronic ester perylenediimides: A next generation building block for dye-stuff synthesis’, Organic Lett. 2011, 13, 3012-3015. 102. Reichelt, H.; Gessner, T.; Muellen, K.; Li, C.; Battagliarin, G. ‘Perylene-based semiconducting materials for org. field-effect transistors’, PCT Int. Appl. 2012, WO 2012117089 A1 20120907. 103. Reichelt, H.; Gessner, T.; Muellen, K.; Li, C.; Battagliarin, G. ‘Perylene-based semiconducting materials’, U.S. Pat. Appl. Publ. 2012, US 20120226042 A1 20120906. 104. Battagliarin, G.; Davies, M.; Mackowiak, S.; Li, C.; Muellen, K. ‘Ortho-functionalized perylenediimides for highly fluorescent water-soluble dyes’, ChemPhysChem 2012, 13, 923-926. 105. Mizoshita, N.; Tani, T.; Shinokubo, H.; Inagaki, S. ‘Mesoporous organosilica hybrids consisting of silica-wrapped π-π stacking columns’, Angew. Chem., Int. Ed. 2012, 51, 1156-1160, S1156/1-S1156/22. 106. Mizoshita, N.; Tani, T.; Inagaki, S. ‘Isothermally reversible fluorescence switching of a mechanochromic perylene bisimide dye’, Adv. Materials (Weinheim, Germany) 2012, 24, 3350-3355. 107. Wang, Baozeng; Zhang, Xinping; Zhang, Jian ‘Influence of plasmonic light-scattering by gold nano-island structures on the quantum efficiency of organic solar cells’, Adv. Materials Research (Durnten-Zurich, Switzerland) 2012, 571(Opto-Electronics Engineering and Materials Research), 160-164. 108. Ning, Liu; Zhang, Xin-Ping; Fei, Dou ‘Heterojunction structure forming in the polymer film doped with small-molecule organic semiconductor’, Wuli Xuebao 2012, 61, 027201/1-027201/6. 109. Reichelt, H.; Gessner, T.; Li, C.; Muellen, K.; Battagliarin, G. ‘Halogenated perylene-based semiconducting materials’, PCT Int. Appl. 2012, WO 2012152598 A1 20121115. 110. Xie, Yuanpeng; Zhang, Xinfu; Xiao, Yi; Zhang, Youdi; Zhou, Fan; Qi, Jing; Qu, Junle ‘Fusing three perylenebisimide branches and a truxene core into a star-shaped chromophore with strong two-photon excited fluorescence and high photostability’, Chem. Comm.s (Cambridge, United Kingdom) 2012, 48, 4338-4340. 111. Liu, Hongmei; Wang, Yongli; Liu, Chenghui; Li, Hongxia; Gao, Baoxiang; Zhang, Licui; Bo, Fuli; Bai, Qianqian; Ba, Xinwu ‘Fluorescent water-soluble probes based on dendritic PEG substituted perylene bisimides: Synthesis, photophysical properties, and live cell images’, J. Materials Chemistry 2012, 22, 6176-6181. 112. Mizoshita, N.; Yamanaka, K.; Hiroto, S.; Shinokubo, H.; Tani, T.; Inagaki, S- ‘Energy and electron transfer from fluorescent mesostructured organosilica framework to guest dyes’, Langmuir 2012, 28, 3987-3994. 113. Yin, Ming; Zhang, Xin-ping; Liu, Hong-mei ‘Effect of annealing temperature on the crystallization and spectroscopic response of a small-molecule semiconductor doped in polymer film’, Guangpuxue Yu Guangpu Fenxi 2012, 32, 3078-3082. 114. Keivanidis, P. E.; Kamm, V.; Zhang, W.; Floudas, G.; Laquai, F.; McCulloch, I.; Bradley, D. D. C.; Nelson, J. ‘Correlating emissive non-geminate charge recombination with photocurrent generation efficiency in polymer/perylene diimide organic photovoltaic blend films’, Adv. Functional Materials 2012, 22, 2318-2326. 115. Savage, R. C.; Orgiu, E.; Mativetsky, J. M.; Pisula, W.; Schnitzler, T.; Eversloh, C. L.; Li, C.; Muellen, K.; Samori, P. ‘Charge transport in fibre-based perylene-diimide transistors: Effect of the alkyl substitution and processing technique’, Nanoscale 2012, 4, 2387-2393. 116. Ito, S.; Hiroto, S.; Shinokubo, H. ‘Synthesis of pyridine-fused perylene imides with an amidine moiety for hydrogen bonding’, Organic Letters 2013, 15, 3110-3113. 117. Rybtchinski, B.; Rajasingh, P.; Shirman, E. ‘Selective bromination of perylene diimides and derivatives thereof under mild conditions’, U.S. 2013, US 8399670 B2 20130319. 118. Puniredd, S. R.; Kiersnowski, A.; Battagliarin, G.; Zajaczkowski, W.; Wong, W. W. H.; Kirby, N.; Muellen, K.; Pisula, W. ‘Polythiophene-perylene diimide heterojunction field-effect transistors’, J. Materials Chemistry C: Materials for Optical and Electronic Devices 2013, 1, 2433-2440. 119. Mizoshita, N.; Tani, T.; Inagaki, S. ‘Luminescent materials containing branched oligomeric siloxanes having bulky substituents’, Jpn. Kokai Tokkyo Koho 2013, JP 2013170182 A 20130902. 120. Moreno-Lopez, J. C.; Grizzi, O.; Martiarena, M. L.; Sanchez, E. A. ‘Initial growth of N,N'-bis(1-ethylpropyl) perylene-3,4,9,10-tetracarboxdiimide films on Cu(100)’, J. Phys. Chem. C 2013, 117, 11679-11685. 121. Edri, E.; Kirmayer, S.; Cahen, D.; Hodes, G- ‘High open-circuit voltage solar cells based on organic-inorganic lead bromide perovskite’, J. Phys. Chem. Lett. 2013, 4, 897-902. 122. Farina, M.; Ye, T.; Lanzani, G.; di Donato, A.; Venanzoni, G.; Mencarelli, D.; Pietrangelo, T.; Morini, A.; Keivanidis, P. E. ‘Fast ultrahigh-density writing of low-conductivity patterns on semiconducting polymers’, Nature Comm. 2013, 4, 3668/1-3668/8. 123. Ye, T.; Singh, R.; Butt, H.-J.; Floudas, G.; Keivanidis, P. E.‘Effect of local and global structural order on the performance of perylene diimide excimeric solar cells’, ACS Appl. Materials & Interfaces 2013, 5, 11844-11857. 124. Zhang, Xinping; Dou, Fei; Liu, Hongmei ‘Charge-transfer complex coupled between polymer and H-aggregate molecular crystals’, J. Polymer Science, Part B: Polymer Physics 2013, 51, 749-755. 125. Sharenko, A.; Proctor, C. M.; van der Poll, T. S.; Henson, Z. B.; Nguyen, T.-Q.; Bazan, G. C. ‘A High-performing solution-processed small molecule: Perylene diimide bulk heterojunction solar cell’, Adv. Materials (Weinheim, Germany) 2013, 25, 4403-4406. 126. Wei, Huimin; Zhao, Nan; Jiang, Nan; Duan, Wenfeng; Gao, Baoxiang ‘The synthesis and electro-optical properties of perylene dicarboximide dimer with electron withdrawing groups’, Advanced Materials Research (Durnten-Zurich, Switzerland) 2014, 936(Material Science and Engineering Technology, 950-954. 127. Sharenko, A.; Gehrig, D.; Laquai, F.; Nguyen, T.-Q. ‘The effect of solvent additive on the charge generation and photovoltaic performance of a solution-processed small molecule: Perylene diimide bulk heterojunction solar cell’, Chemistry of Materials 2014, 26, 4109-4118. 128. Kasi V., Lakshmi C.; Shirtcliff, L. D.; Krishnan, S.; Handa, N. V.; Darrell Berlin, K. ‘Synthesis, photophysical and electrochemical properties of bay-axial perylene diimide-subphthalocyanine dyads’, Tetrahedron Lett. 2014, 55, 4199-4202. 129. Ghosh, I.; Ghosh, T.; Bardagi, J. I.; Koenig, B. ‘Reduction of aryl halides by consecutive visible light-induced electron transfer processes’, Science (Washington, DC, United States) 2014, 346, 725-728. 130. Li, Hongwei; Zhang, Xinping; Zu, Wenbo ‘Photoconductive organic crystals grown on planar substrates with electrode effect’, J. Appl. Physics (Melville, NY, United States) 2014, 115, 054510/1-054510/5. 131. Miyake, G. M.; Theriot, J. C.‘Perylene as an organic photocatalyst for the radical polymerization of functionalized vinyl monomers through oxidative quenching with alkyl bromides and visible light’, Macromolecules (Washington, DC, United States) 2014, 47, 8255-8261. 132. Singh, R.; Giussani, E.; Mroz, M. M.; Di Fonzo, F.; Fazzi, D.; Cabanillas-Gonzalez, J.; Oldridge, L.; Vaenas, N.; Kontos, A. G.; Falaras, P.; et al. ‘On the role of aggregation effects in the performance of perylene-diimide based solar cells’, Organic Electronics 2014, 15, 1347-1361. 133. Savoie, B. M.; Kohlstedt, K. L.; Jackson, N. E.; Chen, L. X.; de la Cruz, M. O.; Schatz, G. C.; Marks, T. J.; Ratner, M. A. ‘Mesoscale molecular network formation in amorphous organic materials’, Proceedings of the National Academy of Sciences of the United States of America 2014, 111, 10055-10060. 134. Schwarz, C.; Milan, F.; Hahn, T.; Reichenberger, M.; Kuemmel, S.; Koehler, A. ‘Ground state bleaching at donor-acceptor interfaces’, Adv. Functional Materials 2014, 24, 6439-6448. 135. Singh, R.; Aluicio-Sarduy, E.; Kan, Z.; Ye, T.; MacKenzie, R. C. I.; Keivanidis, P. E. ‘Fullerene-free organic solar cells with an efficiency of 3.7% based on a low-cost geometrically planar perylene diimide monomer’, J. Materials Chemistry A: Materials for Energy and Sustainability 2014, 2, 14348-14353. 136. Gehrig, D. W.; Roland, S.; Howard, I. A.; Kamm, V.; Mangold, H.; Neher, D.; Laquai, F. ‘Efficiency-limiting processes in low-bandgap polymer: Perylene diimide photovoltaic blends’, J. Phys. Chem. C 2014, 118, 20077-20085. 137. Li, Mingguang; Wang, Lei; Liu, Jiangang; Zhou, Ke; Yu, Xinhong; Xing, Rubo; Geng, Yanhou; Han, Yanchun ‘Cooperative effects of solvent and polymer acceptor co-additives in P3HT:PDI solar cells: simultaneous optimization in lateral and vertical phase separation’, PhysChemChemPhys 2014, 16, 4528-4537. 138. Dobruchowska, E.; Marszalek, T.; Ulanski, J. ‘Anisotropic perylenediimide/polycarbonate composites produced by a single batch solution based method’, Thin Solid Films 2014, 564, 361-366. 139. Li, Mingguang; Liu, Jiangang; Cao, Xinxiu; Zhou, Ke; Zhao, Qiaoqiao; Yu, Xinhong; Xing, Rubo; Han, Yanchun ‘Achieving balanced intermixed and pure crystalline phases in PDI-based non-fullerene organic solar cells via selective solvent additives’, PhysChemChemPhys 2014, 16, 26917-26928. 140. Handa, N. V.; Shirtcliff, L. D.; Lavine, B. K.; Powell, D. R.; Berlin, D. K. ‘1,6- and 1,7-regioisomers of perylene tetracarboxylic dianhydride and diimide: The effects of neutral bay substituents on the electrochemical and structural properties’, Phosphorus, Sulfur and Silicon and the Related Elements 2014, 189, 738-752. 141. Rybtchinski, B.; Shirman, E.; Utstinov, A.; Ben-Shitrit, N.; Weissman, H.; Krieg, E. M.; Golubkov, G.; Baram, J. ‘Supramolecular polymers derived from perylenediimides’, U.S. Pat. Appl. Publ. 2015, US 20150240027 A1 20150827. 142. Rybtchinski, B.; Krieg, E. M.; Weissman, H.; Albeck, S.; Tldhar, Y.; Cohen, E. ‘Separation of nanoparticles using self-assembled perylene diimide membranes’, U.S. Pat. Appl. Publ. 2015, US 20150375180 A1 20151231. 143. Yu, Zhenyi; Wu, Yishi; Liao, Qing; Zhang, Haihua; Bai, Shuming; Li, Hui; Xu, Zhenzhen; Sun, Chunlin; Wang, Xuedong; Yao, Jiannian; et al. ‘Self-assembled microdisk lasers of perylenediimides’, J. Am. Chem. Soc. 2015, 137, 15105-15111. 144. Hendsbee, A. D.; McAfee, S. M.; Sun, J.-P.; McCormick, T. M.; Hill, I. G.; Welch, G. C. ‘Phthalimide-based π-conjugated small molecules with tailored electronic energy levels for use as acceptors in organic solar cells’, J. Materials Chemistry C: Materials for Optical and Electronic Devices 2015, 3, 8904-8915. 145. Shoer, L. E.; Eaton, S. W.; Margulies, E. A.; Wasielewski, M. R. ‘Photoinduced electron transfer in 2,5,8,11-tetrakis-donor-substituted perylene-3,4:9,10-bis(dicarboximides) ’, J. Phys. Chem. B 2015, 119, 7635-7643. 146. Yang, Yang; Li, Gang ‘Multiple donor/acceptor bulk heterojunction solar cells’, PCT Int. Appl. 2015, WO 2015042609 A1 20150326. 147. Chen, Yuxia; Zhang, Xin; Zhan, Chuanlang; Yao, Jiannian ‘In-depth understanding of photocurrent enhancement in solution-processed small-molecule:perylene diimide non-fullerene organic solar cells’, Physica Status Solidi A: Applications and Materials Science 2015, 212, 1961-1968. 148. Chen, H.-C.; Hsu, C.-P.; Reek, J. N. H.; Williams, R. M.; Brouwer, A. M. ‘Highly soluble benzo[ghi] perylenetriimide derivatives: Stable and air-insensitive electron acceptors for artificial photosynthesis’, ChemSusChem 2015, 8, 3639-3650. 149. Liu, Xiujie; Zhang, Qi; Meng, Xiangtai ‘Gold-substituted perylene diimide derivative at bay site’, Faming Zhuanli Shenqing 2015, CN 104262396 A 20150107. 150. Aluicio-Sarduy, E.; Singh, R.; Kan, Z.; Ye, T.; Baidak, A.; Calloni, A.; Berti, G.; Duo, L.; Iosifidis, A.; Beaupre, S.; et al. ‘Elucidating the impact of molecular packing and device architecture on the performance of nanostructured perylene diimide solar cells’, ACS Applied Materials & Interfaces 2015, 7, 8687-8698. 151. Su, Yajun; Li, Yan; Liu, Jiangang; Xing, Rubo; Han, Yanchun ‘Donor-acceptor cocrystal based on hexakis(alkoxy)triphenylene and perylenediimide derivatives with an ambipolar transporting property’, Nanoscale 2015, 7, 1944-1955. 152. Singh, R.; Shivanna, R.; Iosifidis, A.; Butt, H.-J.; Floudas, G.; Narayan, K. S.; Keivanidis, P. E. ‘Charge versus energy transfer effects in high-performance perylene diimide photovoltaic blend films’, ACS Applied Materials & Interfaces 2015, 7, 24876-24886. 153. Moreno-Lopez, J. C.; Grizzi, O.; Sanchez, E. A.‘Thermal Ssability of N,N'-bis(1-ethylpropyl)perylene-3,4,9,10-tetracarboxdiimide films on Cu(100)’, J. Phys. Chem. C 2016, 120, 19630-19635. 154. Weintraub, M. T.; Xhakaj, E.; Austin, A.; Szarko, J. M. ‘The effects of donor : acceptor intermolecular mixing and acceptor crystallization on the composition ratio of blended, spin coated organic thin films’, J. Materials Chemistry C: Materials for Optical and Electronic Devices 2016, 4, 7756-7765. 155. Hendsbee, A. D.; Sun, J.-P.; Law, W. K.; Yan, H.; Hill, I. G.; Spasyuk, D. M.; Welch, G. C.‘Synthesis, self-assembly, and solar cell performance of N-annulated perylene diimide non-fullerene acceptors’, Chemistry of Materials 2016, 28, 7098-7109. 156. Wang, Jialin; Liang, Ziqi ‘Synergetic solvent engineering of film nanomorphology to enhance planar perylene diimide-based organic photovoltaics’, ACS Appl. Materials & Interfaces 2016, 8, 22418-22424. 157. Lindquist, R. J.; Phelan, B. T.; Reynal, A.; Margulies, E. A.; Shoer, L. E.; Durrant, J. R.; Wasielewski, M. R. ‘Strongly oxidizing perylene-3,4-dicarboximides for use in water oxidation photoelectrochemical cells’, J. Materials Chemistry A: Materials for Energy and Sustainability 2016, 4, 2880-2893. 158. Yu, Zhenyi; Wu, Yishi; Zhang, Haihua; Wang, Xuedong; Chen, Jianwei; Yao, Jiannian; Fu, Hongbing ‘Self-assembled 1D-nanowire lasers of perylenediimides’, ChemPhysChem 2016, 17, 3160-3164. 159. Chen, H.-C.; Williams, R. M.; Reek, J. N. H.; Brouwer, A. M. ‘Robust benzo[ghi]perylenetriimide dye-sensitized electrodes in air-saturated aqueous buffer solution’, Chem. Europ. J. 2016, 22, 5489-5493. 160. Yu, Zhenyi; Wu, Yi-Shi; Chen, Jianwei; Sun, Chunlin; Fu, Hongbing ‘ortho-Heterofluorene perylenediimides: synthesis, photophysical and exciton dynamic properties’, PhysChemChemPhys 2016, 18, 32678-32681. 161. Hanson, K.; Hill, S.; Dilbeck, T. ‘Molecular photon upconversion using organic-inorganic hybrid interfaces’, PCT Int. Appl. 2016, WO 2016039976 A1 20160317. 162. Zhu, Xinhai; Sun, Guoquan; Ren, Shuya; Wan, Yiqian; Huang, Manna ‘Method for indirect electrocatalytic synthesis of 2-arylpyrrole compounds’, Faming Zhuanli Shenqing 2016, CN 105568312 A 20160511. 163. Yang, Xiao-Yu; Xu, Wei-Long; Zheng, Fei; Liu, Jian-Qiang; Hao, Xiao-Tao ‘Impact of solvent additive on exciton dissociation in P3HT : EP-PDI blend film via controlling morphology’, Journal of Physics D: Applied Physics 2016, 49, 255502/1-255502/8. 164. Zhang, Hao; Tao, Kai; Liu, Di; Wu, Kui; Wang, Fuyi; Yang, Jingfa; Zhao, Jiang ‘Examining dynamics in a polymer matrix by single molecule fluorescence probes of different sizes’, Soft Matter 2016, 12(35, 7299-7306. 165. Yang, W.; Zhao, J.; Sonn, C.; Escudero, D.; Karatay, A.; Yaglioglu, H. G.; Kucukoz, B.; Hayvali, M.; Li, C.; Jacquemin, D. ‘Efficient intersystem crossing in heavy-atom-free perylenebisimide derivatives’, J. Phys. Chem. C 2016, 120, 10162-10175. 166. Kang, H.; Si, Y.; Liu, J.; Chen, L.; Li, Y.; Chen, H.; Groeper, J.; Yang, B. ‘An experimental and theoretical study of dimethylaminostyryl BODIPY-perylenetetracarboxylic derivative dyads: Synthesis, properties and DFT calculation’, RSC Advances 2016, 6, 23094-23101. 167. Viswanath, L. C. Kasi; Bernhardt, J.; Kumar Gnanasekaran, K.; Want, C.; Frank, J.; Faulkner, J.; Krishnan, S. ‘Alkyl- and aryl-substituted benzo[ghi]perylenetriimides: Synthesis, characterization and comparison of electrochemical and spectroscopic properties’, Dyes and Pigm. 2016, 134, 453-458. 168. Yu, Zhenyi; Wu, Yishi; Peng, Qian; Sun, Chunlin; Chen, Jianwei; Yao, Jiannian; Fu, Hongbing ‘Accessing the triplet state in heavy-atom-free perylene diimides’, Chem. Europ. J. 2016, 22, 4717-4722. 169. Li, Mingguang; Liang, Qiuju; Zhao, Qiaoqiao; Zhou, Ke; Yu, Xinhong; Xie, Zhiyuan; Liu, Jiangang; Han, Yanchun ‘A bi-continuous network structure of p-DTS(FBTTh2)2/EP-PDI via selective solvent vapor annealing’, J. Materials Chemistry C: Materials for Optical and Electronic Devices 2016, 4, 10095-10104. 170. Liu, N.-W.; Liang, S.; Manolikakes, G. ‘Visible-light photoredox-catalyzed aminosulfonylation of diaryliodonium salts with sulfur dioxide and hydrazines’, Adv. Synthesis & Catalysis 2017, 359, 1308-1319. 171. Liang, Qiuju; Han, Jie; Song, Chunpeng; Wang, Zaiyu; Xin, Jingming; Yu, Xinhong; Xie, Zhiyuan; Ma, Wei; Liu, Jiangang; Han, Yanchun ‘Tuning molecule diffusion to control the phase separation of the p-DTS(FBTTh2)2/EP-PDI blend system via thermal annealing’, J. Materials Chemistry C: Materials for Optical and Electronic Devices 2017, 5, 6842-6851. 172. Cohen, E.; Weissman, H.; Shimoni, E.; Kaplan-Ashiri, I.; Werle, K.; Wohlleben, W.; Rybtchinski, B. ‘Robust aqua material: A pressure-resistant self-assembled membrane for water purification’, Angew. Chem., Int. Ed. 2017, 56, 2203-2207. 173. Zhang, Hao; Li, Desheng; Wu, Kui; Wang, Fuyi; Yang, Jingfa; Zhao, Jiang ‘Retarded local dynamics of single fluorescent probes in polymeric glass due to interaction strengthening’, Polymer 2017, 116, 452-457. 174. Dominguez, C.; Baena, M. J.; Coco, S.; Espinet, P. ‘Perylenecarboxydiimide-gold(I) organometallic dyes. Optical properties and Langmuir films’, Dyes and Pigm. 2017, 140, 375-383. 175. Rybtchinski, B.; Cohen, E.; Weissman, H. ‘Perylene diimide based membrane and methods of use thereof in filtration system’, PCT Int. Appl. 2017, WO 2017006325 A1 20170112. 176. Solak, S.; Ricciardulli, A. G.; Lenz, T.; Craciun, N. I.; Blom, P. W. M.; Wetzelaer, G. A. H. ‘Open-circuit voltage loss in annealed P3HT:perylene diimide bulk heterojunction solar cells’, Appl. Phys. Lett. 2017, 110, 163301/1-163301/4. 177. Wang, Helin; Chen, Lingcheng; Xiao, Yi ‘Heterologous perylene diimide arrays: Potential non-fullerene acceptors in organic solar cells’, J. Materials Chemistry C: Materials for Optical and Electronic Devices 2017, 5, 8875-8882. 178. Signoretto, M.; Zink-Lorre, N.; Suarez, I.; Font-Sanchis, E.; Sastre-Santos, A.; Chirvony, V. S.; Fernandez-Lazaro, F.; Martinez-Pastor, J. P. ‘Efficient optical amplification in a sandwich-type active-passive polymer waveguide containing perylenediimides’, ACS Photonics 2017, 4, 114-120. 179. Wang, Jialin; Peng, Jiajun; Liu, Xiaoyu; Liang, Ziqi ‘Efficient and stable ternary organic solar cells based on two planar nonfullerene acceptors with tunable crystallinity and phase miscibility’, ACS Appl. Materials & Interfaces 2017, 9, 20704-20710. 180. Wu, Jiajun; He, Dezhi; Zhang, Li; Liu, Yudong; Mo, Xiaogang; Lin, Jianbin; Zhang, Hui-jun ‘Direct synthesis of large-scale ortho-iodinated perylene diimides: Key precursors for functional dyes’, Organic Lett. 2017, 19, 5438-5441. 181. Wang, Helin; Chen, Lingcheng; Zhao, Zhenbo; Xiao, Yi ‘Aryl-bisalkynyl bridged perylene diimides dimers: Efficient synthesis, properties and improved electron mobilities’, Dyes and Pigm. 2017, 144, 184-189. 182. Tose, L. V.; Murgu, M.; Vaz, B. G.; Romao, W. ‘Application of atmospheric solids analysis probe mass spectrometry (ASAP-MS) in petroleomics: Analysis of condensed aromatics standards, crude oil, and paraffinic fraction’, J. Am. Soc. Mass Spectrometry 2017, DOI:10.1007/s13361-017-17. 183. Wang, Helin; Chen, Lingcheng; Xiao, Yi ‘A simple molecular structure of ortho-derived perylene diimide diploid for non-fullerene organic solar cells with efficiency over 8%’, Journal of Materials Chemistry A: Materials for Energy and Sustainability 2017, 5, 22288-22296.
